100M/1G/2.5G/5G/10G RJ-45 copper ports : 12
SFP+ Ports : 2 (shared)
Form Factor : Rackmount
Packet buffer memory : 3MB
Bandwidth : 240Gbps
MAC Address database size : 32K
VLAN (# supported) : 64
Number of LAGs & number of members : 8 LAGs with max 8 members in each LAG
Supported multicast groups : 128
Max number of source ports allowed (many to one port mirroring) : 11
Fan(s) : 2 (active fans)
IEEE 802.3az (Energy Efficient Ethernet) : Yes
Max power consumption (Watts) : 76.56W
LEDs : Power, Speed, Fan, Link/Activity
Acoustic noise level @ 25° C (dBA) : 29.3dBA
Operating temperature : 0° to 50° C
Electromagnetic compliance (A or B) : A
